ICC CAT6 Patch Panel, UL Listed & PoE++ Rated Gigabit Applications, Wall Mount 12 Port Network Patch Panel with Rear 110 IDC Terminal Blocks and 89D Wall Mount Bracket, Black
Product details
| Management number | 221109509 | Release Date | 2026/05/03 | List Price | US$21.68 | Model Number | 221109509 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
This ICC CAT6 Patch Panel provides high-speed data connectivity for Gigabit Ethernet networks. Designed for wall mounting with an 89D bracket, it offers excellent performance with rear 110 IDC termination blocks, simplifying installation. The panel supports PoE++ up to 100W and is constructed with durable, UL-listed materials, including flame-retardant plastic and phosphor bronze connectors. Numbered ports and color-coded wiring diagrams make management easy, while enhanced crosstalk cancellation ensures signal integrity. It is backward compatible with Cat5e and Cat5 cables, making it versatile for various setups.
- HIGH-PERFORMANCE CONNECTIVITY: Wall-mounted CAT6 component-rated fixed patch panel with an 89D wall mount bracket, delivering excellent performance for data networks requiring maximum speed and bandwidth. Backwards compatible with Cat5e and Cat5 cabling.
- FUTURE-PROOF AND RELIABLE: Designed for Gigabit Ethernet, ensuring your network is future-proof. Ideal for Gigabit Ethernet switches. Gold-plated contacts ensure a correction-free connection with 50 micro-inches of gold over 100 micro-inches of nickel. Supports Power over Ethernet (PoE++) up to 100W.
- EFFICIENT INSTALLATION AND QUICK REFERENCE: Features 110 IDC termination to reduce installation time. The 110 IDC on the rear can be re-terminated over 100 times. Numbered ports and color-coded TIA-568A and TIA-568B wiring diagrams provide quick and easy reference.
- DURABLE MATERIALS AND SAFETY COMPLIANCE: Jack housing constructed from high-impact, flame-retardant plastic (UL 94V-0 rated) and durable phosphor bronze spring wire. Phosphor bronze alloy 110 connectors with 100 micro-inches of nickel alloy. RJ45 jack can accept over 750 plug to jack insertion cycles. UL listed for fire safety compliance.
- ENHANCED CROSSTALK CANCELLATION: Engineered to exceed ANSI/TIA-568 Category 6 connecting hardware requirements with enhanced crosstalk cancellation, reducing return loss and improving overall network performance.
| UPC | 633758011280 168141383502 807034912701 999992719529 777782593029 803982916334 806296599255 163121120627 809390030624 |
|---|---|
| Color | 12-Port Wall Mount Rear IDC - Black |
| Model | ICMPP12V60 |
| Frequency | 1000 MHz |
| Brand Name | ICC |
| Cable Type | Ethernet |
| Unit Count | 1.0 Count |
| Item Weight | 1.2 Pounds |
| Part Number | ICMPP12V60 |
| Manufacturer | ICC |
| Connector Type | RJ45 |
| Number of Pins | 96 |
| Maximum Current | 568 Amps |
| Number of Items | 1 |
| Connector Gender | Male-to-Female |
| Specification Met | RoHS, TIA, UL |
| Compatible Devices | Ethernet Devices, Security Cameras |
| Data Transfer Rate | 1000 Megabits Per Second |
| Indoor Outdoor Usage | Indoor, Outdoor |
| Customer Package Type | Pack of 1 |
| Compatible Phone Models | No Compatible Phone Models |
| Ethernet Cable Category | Cat 6 |
| Global Trade Identification Number | 00633758011280 |
| Other Special Features of the Product | PoE++ Rated to Power Devices |
